Using the GM10F
u
nique
M
odel
f
eaTures
a
lTernaTe
T
herMoCouple
p
osiTion
The GM10F thermocouple is positioned in the center of the kiln. This position gives the most accurate reading
when the glass is located in the center of the kiln. If this thermocouple position is inconvenient for the work you are
doing, it can be moved to an alternate location higher in the chamber. To do this perform the following steps:
1. Unplug the kiln.
2. Remove the back panel of the control box.
3. Remove the screws securing the thermocouple block to the back wall and carefully slide the thermocouple
out. Leave the thermocouple attached to the block.
4. Locate the alternate hole location and use the hole as a guide to drill a 1/4” hole through the brick for the
thermocouple.
5. Slide the thermocouple into the hole and use a 3/32” drill bit to drill pilot holes for the screws that secure
the block.
6. Attach the thermocouple block screws.
7. Stuff previous hole with fiber, replace the back panel and plug in the kiln.
Be sure to test fire the kiln after relocating the thermocouple. The temperature reading at the top of the
chamber may be slightly different, and therefore, you may want to adjust your firing programs to compensate for
the difference.
b
ead
M
aKinG
T
ips
If you have the GM10F but do not have the bead door we highly suggest
you order this option for annealing beads. The bead door is designed to allow
you to insert flame-worked glass beads on a mandrel conveniently and without
losing much heat out of the kiln.
The first step is to program your kiln to heat up to working temperature.
This should take about 20 to 30 minutes. Below is a sample 2-segment bead
program that can be entered in the Ramp/Hold mode on the controller.
To insert the mandrel just lift the door handle with your free hand and
place the bead end of the mandrel through the bead opening. The kiln should
already be on and at the suggested temperature. Rest one end of the mandrel
on a shelf post and the other end on the ledge of the bead opening. Be sure
that the bead is not touching other beads or the post.
When you lower the door there will be a gap between the bottom of the
door and the ledge. This is normal and will not cause any problems. If you
would like to make the gap smaller when you are fusing, just add more fiber
strips until you get a good seal.
When you are done working with the torch you will want to press
“ANNEAL NOW” on the controller. This will advance the kiln program to the annealing schedule you have
programmed. When it is done with the programmed annealing cycle the kiln will shut off.
RATE TEMPERATURE HOLD
SEGMENT 1 9999 980 F 8 HOURS
SEGMENT 2 300 700 F 0 HOURS
