Skutt GlassMaster Kiln User Manual

Page 17

CHG ° (Change from Fahrenheit to Celsius Scale)

The controller can display temperature values in Fahrenheit or Celsius. If the scale is set to display in Celsius an LED

dot will illuminate in the bottom right hand corner of the display. To select a new scale press “ENTER” and it will

automatically toggle to the alternate scale. “ °C ” represents Celsius and “ °F “ represents Fahrenheit.

16-S (16 Segment)

This option links the Ramp and Hold programs stored in memory positions 5 and 6 to create a 16 segment

program. Normally a program is limited to 8 segments.
To program a 16 segment Ramp and Hold program:
1. Enter the first 8 segments of a Ramp/Hold program in the #5 PROG (Program) position.
2. Enter remaining segments of the Ramp/Hold program in the #6 PROG (Program) position.
3. RECALL program # 5 (see RECALL instructions above).
4. Press MENU (The controller must have program #5 loaded in order to see “16-S” in the MENU options.) until

the display reads “SET”, then press ENTER.

5. Press MENU until the display reads 16-S. (16 Segment) and then press ENTER. Use the “1” key to toggle this

feature to the “ON” position. 16-S must be toggled on each time this feature is used.

6. Press ENTER
7. Press REVIEW. Review will only show the information in segment 5. Review will indicate that 16 segments

have been programmed.

8. Press START

MGF (Modify GlassFire Mode)

Modify GlassFire Mode is a feature that can be toggled on or off. When it is toggled “ON” the controller will

display the preset Process Temperature and Process Hold Times when you input a GlassFire Mode program. When

these values are displayed you have the option of adjusting them. If the programs are working well for you and

you do not want yourself or other users adjusting these values, then you may want to toggle this feature “OFF”. If

these values are changed and MGF is toggled to “OFF”, the new values will be automatically inserted for all the

combinations of Process and Speed that were modified. (If you wish to revert back to factory defaults see the

Factory Default menu option instructions)
To change the MGF setting:
1. Press MENU until the display reads “SET”, then press ENTER.
2. Press MENU until the display reads “M-GF” and then press ENTER. Use the “1” key to toggle this feature to the

“ON” position.

3. Press ENTER
