Appendix B – Hydrogen Service Safety System DF-745
93
~
~
~
~
~
~
CASE PURGE VALVE WITH
1/4" COMPRESSION FITTING
SAMPLE DELIVERY INTERLOCK VALVE
WITH 1/4" FEMALE VCR FITTING
3.27 [82.93]
3.07 [77.98]
5.44 [138.24]
.54 [13.70]
1.18 [29.85]
3.07 [77.85]
Figure 85: Hydrogen Service Safety System
