User Interface DF-745
37
The Main Menu is accessed by pressing the Menu key on the front panel. Use the arrow
keys (
and
) to navigate up and down through the list. Select the highlighted item with
the Enter key on the front panel.
If a menu item is grayed out as shown in Figure 21, then the option is not installed, and as a
result the item is not available.
Figure 21: Main Menu (without valve option)
7.4.1 Isolate Analyzer – Optional
Figure 22: Isolate Analyzer
Isolate Analyzer allows the internal gas lines and the moisture sensing cell volume to be
isolated in the case of an impending break in the external delivery lines. It is also considered
the first step in the shut down procedure. Highlight this item and hit the Enter key to
initiate the isolation process. The Isolate Warning shown in Figure 23 will appear for 40
seconds.
