User Interface DF-745 65
7.4.14 Communications
The Communications screen is used to set parameters related to serial PC communications.
Accessed from the System menu, the Next key is used to moved from field to field, and
the arrow keys (
and ) are used to change the numerical digits as well as to select the
baud rate. When done the Next key is used to move to the Accept field and the Enter key
is hit. See page 31 for additional information.
Figure 75: Communications Menu
Figure 76: Communications Setup Screen
7.4.15 Download System Data
In the event that problems develop with the analyzer, the contents of the internal system
data files can easily be downloaded to a USB memory stick, and the files can either be
mailed or e-mailed to Delta F for evaluation. Install a memory stick into the external USB
socket located behind the front door and on the left side of the analyzer. After hitting Enter
from the Download System Data menu, Figure 78 will appear.
The system automatically selects the current date. To change the date, use the Next key to
move between fields and use the arrow keys (
and .
