Page 31
Options DF-745
27
Ш.28 [Ш7.14]
4 PL
MOUNTING FOR
BOTTOM OF BRACKET
5.17 [131.32]
4.92 [124.97]
Ш.28[Ш7.14]
4 PL
MOUNTING FOR
REAR OF BRACKET
Ш.28 [Ш7.14]
4 PL
MOUNTING FOR LEFT OR
RIGHT SIDE OF BRACKET
3.94 [100.08]
2 PL
3.94 [100.08]
2 PL
4.92 [124.97]
6.89 [175.01]
3.94 [100.08]
Figure 12: Vacuum Pump Mount Dimensions
8.54 [216.79]
5.00 [127.00]
9.58 [243.26]
6.18 [156.85]
3.23 [81.98]
10.20 [259.08]
5.00 [127.00]
7.22 [183.39]
6.59 [167.33]
4.31 [109.35]
4.25 [107.95]
2.18 [55.25]
Figure 13: Vacuum Pump Dimensions
