www.desatech.com 118531-01A 8
PRE-INSTALLATION
PREPARATION
Continued
Figure 8 - Side Clearances for Combustible Materials
33°
SAFE
ZONE 1 1 /
2
"
3 3 /
4
"
6"
5 1 /
2
"
12"
Perpendicular
Side Wall
Combustible
Material May
Be Used
Outer Surround
To Fireplace
Opening
C
B
A
D
E
F
G
3
2
1
4
5
6
7
Ref.
Mantel
Depth Ref.
Mantel from
Top of Louver
Opening
1 1" A 14"
14" A 1"
3 1" B 10"
4 10" C 8"
5 8" D "
4" F 4"
" G "
Figure 7 - Clearances for Combustible Mantels
MANTEL CLEARANCES
Figure 7 shows projected mantel depths at various
heights above the top of the louver opening. Figure
8 shows the minimum allowable distances from
various mantel components in relation to the both
sides of the fireplace opening.
WARNING: When finishing
appliance, do not overlap com-
bustible materials onto the black
front face. Brick, tile, or other non-
combustible materials may be
applied to the face provided that
any fireplace openings are not
blocked and gaps in the material
used and the face are sealed with
a noncombustible caulking.
