PARTS LIST
FIREPLACE ASSEMBLy FOR MODEL CD36TN-M
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 38 of this manual.
KEy
NO.
PART NO. DESCRIPTION QTy.
1 11108-01 Log Set 1
1-1 11109-01 Burner Base Log 1
1- 11110-01 Rear Log 1
1-3 11180-05 Right Top Log 1
1-4 11180-04 Left Top Log 1
11515-01 Burner Assembly Complete 1
3 114889-01 Junction Box Duplex Plug 1
4 114880-01 Heat Deflector 1
5 11485-0 Fireplace Surround 1
1148-0 Fireplace Top 1
1101-0 Fireplace Top Insulation 1
8 11483-01 Louver Bottom Assembly 1
9 1148-01 Louver Top Assembly 1
10 11481-01 Glass Door Assembly 1
11 1148-01 Face Assembly 1
1 ** Firebox Assembly Complete 1
13 11093-01 Cover Junction Box
14 440 Gas Conduit Assembly
15 111 Gas Knock-Out Cover
1 14418 Duplex Plug Receptacle 1
1 1413 Bushing Universal Strain Relief 1
18 11408 Bushing 0.5" Electric
19 90 Firebox Leg
PARTS AVAILABLE - NOT SHOWN
5580 Ember Bag Assembly 1
53 Notice Label 1
5540 Vent Label 1
11853-01 LP Gas Conversion Kit 1
** Not a field replaceable part.
