Installation
Introduction
Installation procedures are similar for all frames covered under this manual. However, differences
between video frame and audio frame installation exist. Exceptions, if any, have been noted in each of
the following paragraphs.
Video Frame Rack Mounting
Carefully inspect the frame to ensure that there has been no shipping damage. Make sure all modules
are seated completely in the frame.
Each of the Yosemite video routing switchers described in this manual can be rack mounted in a standard
19" (RU) EIA rack assembly and includes integrated rack "ears" at each side of the front of the frames.
