ELECTRICAL CHARACTERISTICS CURVES
60
70
80
90
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
OUTPUT CURRENT (A)
EFFI
CI
ENCY (
%
)
1
2
3
4
5
6
7
8
9
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
OUTPUT CURRENT (A)
LO
SS (
W
)
Figure 1: Efficiency vs. load current for minimum, nominal, and
maximum input voltage at 25°C Figure 2: Power dissipation vs. load current for minimum,
nominal, and maximum input voltage at 25°C.
0
0.3
0.6
0.9
1.2
1.5
1.8
2.1
2.4
2.7
3
3.3
16 21 26 31 36 41 46 51 56 61 66 71
INPUT VOLTAGE(V)
IN
PUT
CURRENT
(A)
Figure 3: Typical full load input characteristics at room
temperature
75Vin
18Vin
24Vin
48Vin
24Vin
18Vin
48Vin
75Vin
DS_L36SA3R315_02142007
