TECHNICAL SPECIFICATIONS
(T
A
=25°C, airflow rate=300 LFM, V
in
=48Vdc, nominal Vout unless otherwise noted.)
PARAMETER NOTES and CONDITIONS L36SA3R315 (Standard)
Min. Typ. Max. Units
ABSOLUTE MAXIMUM RATINGS
Input Voltage
Continuous 80 Vdc
Maximum input voltage 100 Vdc
Operating Temperature Refer to Figure21 for measuring point -40 130 °C
Storage Temperature -55 125 °C
Input/Output Isolation Voltage 2250 Vdc
INPUT CHARACTERISTICS
Operating Input Voltage 18 75 Vdc
Input Under-Voltage Lockout
Turn-On Voltage Threshold 16 17 18 Vdc
Turn-Off Voltage Threshold 15 16 17 Vdc
Lockout Hysteresis Voltage 0.75 1 1.5 Vdc
Maximum Input Current 100% Load, 18Vin 4 A
No-Load Input Current 40 mA
Off Converter Input Current 4 mA
Inrush Current(I 2 t) 1 A 2 s
Input Reflected-Ripple Current P-P thru 12µH inductor, 5Hz to 20MHz 20 mA
Input Voltage Ripple Rejection 120 Hz 60 dB
OUTPUT CHARACTERISTICS
Output Voltage Set Point Vin=48V, Io=Io.max, Tc=25°C 3.267 3.3 3.333 Vdc
Output Voltage Regulation
Over Load Io=Io,min to Io,max ±5 ±15 mV
Over Line Vin=18V to 75V ±5 ±10 mV
Over Temperature Ta=-40°C to 85°C ±30 mV
Total Output Voltage Range Over sample load, line and temperature 3.25 3.35 V
Output Voltage Ripple and Noise 5Hz to 20MHz bandwidth
Peak-to-Peak Full Load, 1µF ceramic, 10µF tantalum 40 80 mV
RMS Full Load, 1µF ceramic, 10µF tantalum 10 20 mV
Operating Output Current Range 0 15 A
Output over current protection 110 150 %
DYNAMIC CHARACTERISTICS
Output Voltage Current Transient 48V, 10µF Tan & 1µF Ceramic load cap, 0.1A/µs
Positive Step Change in Output Current 50% Io.max to 75% Io.max 80 mV
Negative Step Change in Output Current 75% Io.max to 50% Io.max 80 mV
Settling Time (within 1% Vout nominal) 150 us
Turn-On Transient
Start-Up Time, From On/Off Control 20 ms
Start-Up Time, From Input 20 ms
Maximum Output Capacitance Full load; 5% overshoot of Vout at startup 4000 µF
EFFICIENCY
100% Load 87 %
60% Load 87 %
ISOLATION CHARACTERISTICS
Input to Output 2250 Vdc
Isolation Resistance 100 MΩ
Isolation Capacitance 1500 pF
FEATURE CHARACTERISTICS
Switching Frequency 300 kHz
ON/OFF Control, Negative Remote On/Off logic
Logic Low (Module On) Von/off at Ion/off=1.0mA 0.7 V
Logic High (Module Off) Von/off at Ion/off=0.0 µA 2 18 V
ON/OFF Control, Positive Remote On/Off logic
Logic Low (Module Off) Von/off at Ion/off=1.0mA 0.7 V
Logic High (Module On) Von/off at Ion/off=0.0 µA 2 18 V
ON/OFF Current (for both remote on/off logic) Ion/off at Von/off=0.0V 1 mA
Leakage Current (for both remote on/off logic) Logic High, Von/off=15V 50 uA
Output Voltage Trim Range Across Pins 9 & 5, Pout ≦ max rated power -10% 10% %
Output Voltage Remote Sense Range (option) Pout ≦ max rated power 10 %
Output Over-Voltage Protection Over full temp range; % of nominal Vout 4 V
GENERAL SPECIFICATIONS
MTBF Io=80% of Io, max; Ta=25°C 3.7 M hours
Weight 24.2 Grams
Over-Temperature Shutdown Refer to Figure21 for measuring point 134 °C
DS_L36SA3R315_02142007
