D-Link DSL 2740B - Manual (Page 29)

DSL-2740B Wireless ADSL Router User Guide
19
Additional configurations available for PPP connection:
PPP Connection
Parameters Description
Dial on demand The Dial on demand function, if checked, will tear down the PPP link
automatically when there is no incoming/outgoing packet via WAN interface
for the programmed period of time that is set below (in minutes). Router
activates PPPoE connection automatically when user wants to access
Internet and there is no active PPPoE connection.
PPP IP extension Router passes the obtained IP address to the local PC and acts as a bridge
only modem.
Use Static IP Address Type in the IP address given by your ISP in this field if your Router’s IP
address is not dynamically assigned.
Enable PPP Debug Mode Enable PPP debug mode so you can see the PPP authentication process
from Router Status Æ System Log.
