REMKO SuperTec-Monitor - Manual (Page 9)

Hot gas temperature TH4
3 – 217
Number of switch on/off pro-
cedures of the condenser
0 – 9999
3 – 217
If the temperature sensor
measures values above 99°C,
the display switches between
the 100s digit, 10s and 1s dig-
its, and 2 spaces.
Example: TH4 = 105°C:
0 – 9999
If the number is above 99, the
display switches between
the 100s digit, the 10s and 1s
digits, and 2 spaces.
Ex-
ample: 42500 switching proc.:
425 × 100
0.5 s 0.5 s 2 s
„ 1“ „05“ „ “
0.5 s 0.5 s 2 s
„ 4“ „25“ „ “
°C
X 100
ON
1 2 3 4 5 6
Setting on SW2 System component Measuring range and description Unit
Line temperature TH3
-40 – 90
-40 – +90
If the temperature sensor
measures values below 0°C,
the display switches between
the sign, the value,
and 2 spaces.
Example: TH3 = -10°C:
0.5 s 0.5 s 2 s
„- “ „10“ „ “
°C
ON
1 2 3 4 5 6
Switch assignment of DIP switch SW2
Fan speed (outdoor unit)
0 – 10
0 – 10 Levels /
Steps
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
