63
Connect Video
Cables –
The back panels of
your equipment may not
look exactly like those
illustrated.
SATELLITE IN
S-VIDEO
OUT
DIGITAL
HDMI
AC IN
RF REMOTE
ANTENNA
PHONE
JACK
DIRECTV HD ® Receiver
RF
AN
SATELLITE IN DIGITAL AC IN
REMOTE
NTENNA
PHONE
JACK
Television Television COMPONENT IN
S-VIDEO
IN
S-VIDEO HDMI (includes
video & audio)
HDMI
DIGITAL
AUDIO IN
(OPTICAL)
DIGITAL AUDIO IN
(COAXIAL)
S-VIDEO HDMI
*Note: Do not confuse the component YPbPr cable with a standard
Audio/Video (RCA-type) cable. Observe the Red, Green, Blue color-coding.
You will not get HD video if you use the Video Out connector on your
DIRECTV HD Receiver or TV.
GOOD
BETTER*
BEST
