Indoor unit RVT 523 DC IT

3

4

CE-KFR50G/BP3N1Y-11M.D.11.NP2-1

202302130861

CN9

CN11

CN10A

CN12-2

CN8

CN12-1

CN4

S

W

1

L_IN

L_OUT

CN5

A

1

3

B

C

2

4

5

6

Fig. 51: Electrical drawingsRVT 523 DC IT

A: Supply terminal contact = L

B: Supply terminal contact = 1

C: Supply terminal contact = N

1: Evaporator fan motor

2: Display

3: Probe evaporator

4: Air circulation probe

5: Swing motor 1

6: Ion generator
