16
COMPOUND BOW
USER’S GUIDE
INFORMATION ON DRAW STOP ADJUSTMENTS:
DRAW STOP:
The position of the draw stop must match the setting on the inner-cam. For example, if the cam is set
on “E”, the draw stop must be placed in one of the draw stop holes marked with an “E”. If the inner-
cam is in the “B” setting, the stop must be in the “B” position. Certain hybrid cams have top and
bottom stops. They can be shot with both stops for a harder “wall” or with only the top stop for a
softer “wall”. Never shoot hybrid cams with the two stop option with only the bottom stop. In either
case, the stops need to be in the holes marked with the same marking as the inner-cam setting.
The Ultra Fast (UF) hybrid cam system (Fig. A) has two valley settings-
long and short. When using top and bottom stops for a hard “wall”
both stops need to be in the same hole designation-long or short.
SETTING PROPHECY
BOW
MADNESS 3G
SINISTER BRUTE X STINGER 3G CHAOS ONE
A 30 30 30 1/2 30 30 1/2 29
B 29 1/2 29 1/2 30 29 1/2 30 28 1/2
C 29 29 29 1/2 29 29 1/2 28
D 28 1/2 28 1/2 29 28 1/2 29 27 1/2
E 28 28 28 1/2 28 28 1/2 27
F 27 1/2 27 1/2 28 27 1/2 28 26 1/2
G 27 27 27 1/2 27 27 1/2 26
H 26 1/2 26 1/2 27 26 1/2 27 25 1/2
I 26 26 26 1/2 26 26 1/2 25
J 25 1/2 25 1/2 26 25 1/2 26 24 1/2
K 25 25 25 1/2 25 25 1/2 24
PSE MAIN LINE BOWS:
DRAW SETTING CHART
UF Cam (Omen Max)
Figure A
