OLP
Three Phase UPS Systems
5. LCD DISPLAY
5-12
When CHARGE CURRENT is selected, the charging current values that can be
selected will be shown (LO/ME/HI). When the batteries are being boost-charged
for whatever the reason, the charging current will be limited by a value according
the setting in this row. The current value (or the being selected) will flash, and is
confirmed by the ENTER (← ┘ ) key.
The values that can be selected as a rule are listed below:
BACK-UP TIME SETTING
10 – 30 MIN LO
30MIN – 1HOUR ME
> 1 HOUR HI
If “EXIT” is selected (blinking instead of pointed by cursor), the screen will go
back to the MENU 5- the PARAMETER SETTING menu.
5.12. Menu 11 – Date/Time Setting Menu
→ Y E A R = X X X X H O U R ( 2 4 H ) = X X
M O N T H = X X M I N U T E = X X
D A Y = X X D A Y O F T H E W E E K = M O N E X I T
＜ D A T E T I M E S E T T I N G ＞
This menu is displayed when the item < DATE/TIME > is selected from MENU 5,
t h e P A R A M E T E R S E T T I N G m e n u . T h e u s e r c a n c h a n g e t h e
YEAR/MONTH/DAY/, HOUR/MINUTE/DAY OF THE WEEK of the real time
clock through this menu. Once this menu is opened, the present value in the real
time clock will be shown. The cursor (→) can be moved upward by the UP( ↑ )
key, and can be moved downward by the DOWN( ↓ ) key to the item the user
wants to change. The selection is confirmed by pressing the ENTER (← ┘ ) key.
See the figure above. The values to be entered are numbers except the DAY OF
THE WEEK (MON, TUE... provided for user selection). The values that can be
entered are restricted to certain values according to which item is being set (the
values are listed below).
- YEAR : 1998 – 2097
