OnLine Power Battery Backup System - Manual (Page 31)

OLP
Three Phase UPS Systems
2. TECHNICAL
3
KVA 80 100 120 160
OVERALL CHARACTERISTICS
OVERALL EFFICIENCY 92.5% 92.5% 93% 93%
OPERATING ENVIRONMENT:
- TEMPERATURE 0 -40℃ ( 32 - 104℉ )
- HUMIDITY 0% - 90% ( NON–CONDENSING )
- ALTITUDE <1500 M ABOVE SEA LEVEL
TYPICAL HEAT
DISSIPATION (BTU)
5280 6600 7900 10,533
WEIGHT(lbs) (No Battery) 1760 2420 2860 3300
DIMENSION:
- HEIGHT 62”
- WIDTH 43”
- DEPTH 22”
- AUDIBLE NOISE < 65 dBA (@ 1 m)
STANDARDS:
- EN50091-1,-2 YES
- FCC CLASS A YES
PROTECTIONS:
- SHORT CIRCUIT RECTIFIER, RESERVE, BYPASS NFB
- LIGHTNING MOV
- EMC FILTER INPUT & OUTPUT
- GALVANIC ISOLATION BETWEEN INPUT & OUTPUT
DATA DISPLAY BY LCD YES
INDICATIONS & ALARMS:
- LED,LCD,BUZZER YES
DRY CONTACT YES
BATTERY START YES
☆ All specifications are subject to change without prior notice.
