5. LCD DISPLAY
5-9
The UP (↑ ) or DOWN (↓ ) keys have no function in this menu. The screen will
go back to MENU 3 – the REAL TIME DATA menu, when ENTER(← ┘ ) is
pressed.
5.10. Menu 9 – Reserve Data Menu
This menu is displayed when is selected from MENU 3 – the
REAL TIME DATA MENU,. It is a data display menu, which shows real time
data of the reserve input, such as, RESERVE FREQUENCY, R-N / S-N / T-N
VOLTAGE, etc., for the user’s reference. The phase to phase voltage display is
also available when reserve input is a delta (△ ) connected source.
The UP (↑ ) or DOWN (↓ ) keys have no function in this menu. The screen will
go back to MENU 3 – the REAL TIME DATA menu, when ENTER (← ┘ ) is
pressed.
5.11. Menu 10 – Boost Charge Setting Menu
＜ O T H E R D A T A ＞
T E M P E R A T U R E = X X C
D C V O L T A G E = X X X V d c
D I S C H A R G E C U R R E N T = X X X A
R - N = X X X V a c S - N = X X X V a c T - N = X X X V a c
HZ F R E Q U E N C Y = X X E R V E S R E
< R E S E R V E D A T A >
＜ B O O S T C H A R G E S E T T I N G ＞
→ A U T O - B O O S T ( M O N T H ) = 0 4
A U T O - B O O S T ( B A T T L O W ) = 0 8
C H A R G E C U R R E N T = L O E X I T
