OnLine Power Battery Backup System - Manual (Page 29)

OLP
Three Phase UPS Systems
2. TECHNICAL
1
2.1. 80KVA ~ 160KVA UPS 3-Phase Input / Output
TECHNICAL SPECIFICATION
KVA 80 100 120 160
RECTIFIER
INPUT VOLTAGE 480/277VAC 3 Phase 4 Wire
INPUT RANGE +/- 20%
INPUT FREQUENCY 50 / 60 Hz +/- 7%
INPUT POWER FACTOR 0.8
NORMAL INPUT CURRENT(A) 10 12 13 16
OCPD CURRENT(A) 125 150 200 250
POWER WALK IN 0% - 100% : 20 sec
EFFICIENCY 99%
VOLTAGE REGULATION 1%
PEAK CURRENT LIMIT(A) 187 234 312 374
RIPPLE VOLTAGE 0.5%
BATTERY
BATTERY TYPE SEAL LEAD ACID
NO. OF CELLS 174
VOLTAGE RANGE 295 – 410VDC
MAXIMUM CHARGE
CURRENT (AD C)
10 10 10 15
BATTERY LOW VOLTAGE 320VDC
BATTERY LOW STOP VOLTAGE 295 VDC
BOOST CHARGE 402 VDC
FLOAT CHARGE 390VDC
