Delta Electronics PFB1212EHE - Manual

Operating
Voltage
Range
MODEL
Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure
Noise
PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A
2 2
92
120 x 120 x 38 MM SERIES
PFB
DIMENSIONS DRAWING
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT Bearing Type
Ball Bearings
Material
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
UL 1007 AWG #24 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 380g (13.40 oz) *
*
*
LABEL
UNIT:
(INCH)
mm
mm
(INCH)
UNIT:
http://www.deltaww.com
*
OUTLET SIDE INLET SIDE
* Function type is optional.
The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
Noise is measured in anechoic chamber in free air, one meter from intake side.
All readings are typical values at rated voltage.
Specifications are subject to change without notice. *
*
*
*
PFB1212EHE -R00 / -F00 12 8.0 to 13.2 1.60 19.20
PFB1224EHE -R00 / -F00 24 14.0 to 26.5 0.90 21.60 4000 5.133 181.27 19.078 0.751 59.0
PFB1248EHE -R00 / -F00 48 30.0 to 56.0 0.45 21.60
PFB1212GHE -R00 / -F00 12 8.0 to 13.2 2.70 32.40
PFB1224GHE -R00 / -F00 24 14.0 to 26.5 1.35 32.40 4800 6.167 217.80 27.308 1.075 64.0
PFB1248GHE -R00 / -F00 48 30.0 to 56.0 0.68 32.64
PFB1212UHE -R00 / -F00 12 8.0 to 13.2 4.00 48.00
PFB1224UHE -R00 / -F00 24 14.0 to 26.5 2.00 48.00 5500 7.160 252.85 35.877 1.412 66.5
PFB1248UHE -R00 / -F00 48 30.0 to 56.0 1.00 48.00
Input
Power
Input
Current
