ME38-ODV-2 Homefire
Part No. XG0123
Introduction
About the ME38-ODV-2 Fireplaces:
The ME38-ODV-2 includes a 22,000 BTU dual burner, and is ap-
proved for outdoor use. The ME38-ODV-2 model is available in two
versions:
 Top Vent (Product Code ME38ODT2)
 Rear Vent (Product Code ME38ODR2)
The ME38-ODV-2 is rated for Natural Gas at 22,000 BTU/H (6.45
Kilowatts) Input or Propane at 22,000 BTU/H (6.45 Kilowatts) Input.
How to use this manual:
This manual covers all models and unless otherwise specified, the
designation ME38-ODV-2 refers to all models. Sections which are
specific to a particular model are marked with a
sym-
bol, plus the appropriate model number.
Warranty and Installation Information:
The Montigo warranty will be voided by, and Montigo disclaims any
responsibility for, the following actions:
 Modification of the fireplace and/or components including Direct-
Vent assembly or glass doors.
 Use of any component part not manufactured or approved by
Montigo in combination with this Montigo fireplace system.
 Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements
for factory-built gas fireplaces. Installation & repairs should be done
by a qualified contractor.
Installations in Canada must conform to the current CAN/CGA
B-149.1 and .2 Gas Installation Code and local regulations. If the
optional air-circulating fan kit is installed, it must be electrically
grounded in accordance with CSA C22.1 Canadian Electrical Code
Part 1 and/or Local Codes.
Installations in the USA must conform to local codes, or in the
absense of local codes to the National Fuel Gas Code, ANSI Z223.1-
1988. If the optional air-circulating fan is installed, it must be ground-
ed in accordance with local codes or, in the absence of local codes,
with the National Electrical Code, ANSI/NFPA 70-1987.
Table Of Contents
Introduction ............................................................................... 2
Installation
Installing the Fireplace Shell .......................................... 3
Installing the Gasline ...................................................... 4
The Remote Switch ........................................................ 4
Direct Vent Installation ................................................... 4
General Requirements ...................................... 4
Terminations ...................................................... 5
Top Vent Models with horizontal runs ................ 6
Top Vent Models with vertical runs .................... 8
Rear Vent Models .............................................. 9
Construction around the fireplace
Facing .............................................................. 11
Mantels and Surrounds ................................... 11
Removing and Installing the Insert ............................... 12
Removing and Installing the Door ................................ 12
Installing the Logset ..................................................... 13
Installing the Trim ......................................................... 13
Operation ............................................................................13-14
Maintenance ............................................................................ 15
Warranty .................................................................................. 16
Appendix
A. Termination Locations .............................................. 17
CAUTIONS
Due to its high operating temperatures, the appliance
should be located out of traffic & away from furniture and
draperies.
 Children and adults should be alerted to the hazards
of the high surface temperature, which could cause
burns or clothing ignition.
 Young children should be carefully supervised when
they are in the same room as the appliance.
 Clothing or other flammable materials should not be
placed on or near the appliance.
 Solid Fuel will not be burned in this fireplace.
For Your Safety
Installation and repair should be done by a qualified service
person. The appliance should be inspected before use
and at least annually by a qualified service person. More
frequent cleaning be required as necessary. It is imperitive
that control compartment, burners and circulating air pas-
sageways of the appliance be kept clean.
