154

Automatic adjustment occurs for lens focal
lengths from 24 mm.

The automatic adjustment will not be activa-
ted if the reflector is swivelled, if the wide-
angle diffuser

ቪ is pulled out, or a

Mecabounce (accessory) is mounted.

If so desired, the position of the reflector can
be manually adjusted in order to achieve par-
ticular lighting effects (such as spot effect
etc.).

Manual zoom mode

The zoom position of the reflector must be
adjusted manually to the lens focal length
when used with a camera that doesnít trans-
mit the data related to the lens focal length.

In this case auto-zoom mode is not possible!

After switching on the flash unit, „Zoom“
appears in the display and the current zoom
position of the reflector appears.

Setting procedure

• Press the

ቨ button as often as it takes

for the selection menu to appear.

• Press the

sensor button on the

touch display.

• Press the

sensor buttons on the

touch display and select "Zoom".

• Press the

sensor button on the

touch display.

• Press the

sensor buttons on the

touch display and select the desired zoom
value.

• Press the selected correction value on the

touch display, e.g

After around 10 seconds, the operation dis-
play appears, or press the

ቨ button

repeatedly until the operation display
appears. The following zoom positions are
possible for the reflector:

24 - 28 - 35 - 50 - 70 - 85 - 105 mm
(35 mm format).

Tip:

If you do not necessarily need the full guide
number and maximum flash range of the
flash unit, you can leave the zoom reflector at
the position for the shortest focal length of
the zoom lens.

PARA

Zoom

ZOOM
