Table 7. Single-ended mode pin out
Pin
Signal Name
Pin
Signal Name
1
+5V PC Bus
20
CTR2 Out
2
CTR0 Out
21
CTR0 Clock
3
DOUT3
22
DOUT2
4
DOUT1
23
DOUT0
5
DIN3
24
DIN2 / CTR2 Gate
6
DIN1
25
DIN0 / Trigger
7
DGND
26
SS&H OUT
8
-5 Ref Out
27
N/C
9
N/C
28
LLGND
10
N/C
29
LLGND
11
CH15 HI
30
CH7 HI
12
CH14 HI
31
CH6 HI
13
CH13 HI
32
CH5 HI
14
CH12 HI
33
CH4 HI
15
CH11 HI
34
CH3 HI
16
CH10 HI
35
CH2 HI
17
CH9 HI
36
CH1 HI
18
CH8 HI
37
CH0 HI
19
LLGND
Table 8. Differential mode pin out
Pin
Signal Name
Pin
Signal Name
1
+5V PC Bus
20
CTR2 Out
2
CTR0 Out
21
CTR0 Clock
3
DOUT3
22
DOUT2
4
DOUT1
23
DOUT0
5
DIN3
24
DIN2 / CTR2 Gate
6
DIN1
25
DIN0 / Trigger
7
DGND
26
SS&H OUT
8
-5 Ref Out
27
N/C
9
N/C
28
LLGND
10
N/C
29
LLGND
11
CH7 LO
30
CH7 HI
12
CH6 LO
31
CH6 HI
13
CH5 LO
32
CH5 HI
14
CH4 LO
33
CH4 HI
15
CH3 LO
34
CH3 HI
16
CH2 LO
35
CH2 HI
17
CH1 LO
36
CH1 HI
18
CH0 LO
37
CH0 HI
19
LLGND
