Installing the PCIM-DAS16JR/16
Pin out – main I/O connector
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
+5V PC Bus Power
CTR 1 OUT
DIG Out 3
DIG Out 1
DIG In 3
DIG In 1
DIG Gnd
Ch7 /
Ch15
High
Ch6
/ Ch14
Ch5 /
Ch13
Ch4 /
Ch12
Ch3
/ Ch11
Ch2 /
Ch10
Ch1 /
Ch9
Ch0 Low / Ch8
GND
N/C
N/C
N/C
Low
Low High
Low High
Low High
Low High
Low High
Low High
High
A
CTR 1 Clock In
DIG Out 2
DIG Out 0
DIG In 2/CTR1 Gate
SS&H Out
N/C
AGND
AGND
CH7 High
CH6 High
CH5 High
CH4 High
CH3 High
CH2 High
CH1 High
CH0 High
PCI Slot
Figure 2-5. Main I/O connector
Cabling
You can use the C37FF-x or C37FFS-x 37-pin cable to connect signals to the PCIM-DAS16JR/16 board.
20
1
37
19
20
1
37
19
The red stripe
identifies pin # 1
Figure 2-6. C37FF-x cable
20
1
37
19
20
1
37
19
Figure 2-7. C37FFS-x cable
2-6
