Main connector and pin out – Measurement Computing PCI-DIO96H User Manual
Page 18
PCI-DIO96H User's Guide
Specifications
18
Main connector and pin out
Table 5. Main connector specifications
Connector type
100-pin, high-density
Compatible cables
C100FF- x
Compatible accessory products
CIO-MINI50*
CIO-SPADE50*
CIO-TERM100
SCB-50
CIO-ERB24
CIO-SERB24
CIO-ERB48
CIO-SERB48
SSR-RACK24
SSR-RACK48
* two devices are required
