91
1
Set up the zone mode
Press
MAIN
to switch the zone mode.
MAIN
lights.
Press MAIN
2
Connect the Setup and
measurement microphone.
Audyssey Setup
Channel Select
Amp Assign
Check Results
Restore...
Start
Your AV receiver can automatically measure the acoustics of
your room then optimize your speakers using the included
microphone.
Set the following items
if necessary.
When the Setup and
measurement microphone is
connected, the following screen is
displayed.
Set up speakers
around items indicate the settings.
This section describes detailed settings for Audyssey® Setup.
First install and connect the speakers to this unit.
Before Audyssey® Setup measurement, the settings shown below can be made.
• Changing the amplifier assignment (Amp Assign)
The signal output from the SURROUND BACK speaker terminals of this unit can be switched to match your speaker environment (
• Setting the channels to be used (Channel Select)
If channels that are not to be used are set in advance, measurement for the set channels is skipped, and measuring time can be reduced. You can also change the number of surround back speakers (
3
Set up “Amp Assign”
Use
ui
to select “Amp Assign”, and then press
ENTER
.
Amp Assign
[1/2]
Assign Mode
Surround Back
ZONE2:
Selects how to use the internal amplifiers
Front
Center
Surround
Surr. Back
ZONE2
Speaker
Speaker
Speaker
Speaker
Not Used
Audyssey Setup
Channel Select
Amp Assign
Check Results
Restore...
Start
Your AV receiver can automatically measure the acoustics of
your room then optimize your speakers using the included
microphone.
Set the following items
if necessary.
4
Select “Assign Mode”, and then press
ENTER
.
Basic instructions
Advanced instructions
Information
Advanced instructions
v See overleaf
