Delta Electronics SIR106 User Manual
Smt power inductor, Sir106 type, Features
17
o
25 C, 10~82uH 100KHz, 0.1V. 100~470uH 1KHz, 1V.
SMT Power Inductor
SIR106 Type
Features
RoHS compliant.
mounting.
Low profile (5.5mm max. height) SMD type.
Magnetically shielded.
Self-leads, suitable for high density
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
0.00
0.01
0.10
1.00
10.00
CURRENT (A)
1.00
10.00
100.00
1000.00
IN
D
U
C
T
A
N
C
E
(u
H
)
100
120
150.
180
220
270
330
470
560
680
820
101
390
121
151
181
221
271
331
391
471
Electrical Characteristics:
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
SIR106 - 100
10
0.06
2.06
SIR106 - 120
12
0.07
1.94
SIR106 - 150
15
0.07
1.72
SIR106 - 180
18
0.08
1.58
SIR106 - 220
22
0.08
1.42
SIR106 - 270
27
0.10
1.32
SIR106 - 330
33
0.11
1.16
SIR106 - 390
39
0.12
1.10
SIR106 - 470
47
0.14
1.00
SIR106 - 560
56
0.19
0.93
SIR106 - 680
68
0.21
0.85
SIR106 - 820
82
0.28
0.79
SIR106 - 101
100
0.34
0.72
SIR106 - 121
120
0.37
0.63
SIR106 - 151
150
0.51
0.55
SIR106 - 181
180
0.57
0.50
SIR106 - 221
220
0.78
0.47
SIR106 - 271
270
0.87
0.41
SIR106 - 331
330
1.20
0.37
SIR106 - 391
390
1.34
0.35
SIR106 - 471
470
1.50
0.33
PART NO.
DCR
( ) MAX
2
Irated
(Adc)
1
1
L
(uH)
1. Tolerance of inductance: 20% for 10~27uH, 15% for 33~82uH, 10% for 100~470.
2. Irated is the DC current which cause the inductance drop 10% typical of its nominal inductance without current
and the surface temperature of the part increase less than 45
3. Operating temperature : -20
to 105
(including self-temperature rise).
o
C.
o
o
C
C
10.0
D
C
A
B
4.4
1.8
Mechanical Dimension:
UNIT:mm/inch
A = 10.0 0.4 / 0.394 0.016
B = 9.0 0.4 / 0.354 0.016
C = 5.0 0.5 / 0.197 0.020
D = 1.5 0.2 / 0.059 0.008
¡У
¡У
¡У
¡У
¡У
¡У
¡У
¡У
RECOMMENDED PAD PATTERNS
