Delta Electronics Optical Transceiver Modules LC-155Axxxxx User Manual
Page 3
LC-155Axxxxx
DELTA ELECTRONICS, INC.
www.deltaww.com
3
Jan., 2008
Rev. :0F
NRZ, PRBS=2
23
-1 and E.R= 9dB.
Pin Definition
PIN Symbol
Functional description
1 GND
Receiver
Signal
Ground
2 VccR
Receiver
Power
Supply
3
SD
Receiver Signal Detect (LVPECL or LVTTL)
4
RD(-)
Receiver Data Out Inverted (LVPECL)
5
RD(+)
Receiver Data Out Non-inverted (LVPECL)
6
VccT
Transmitter Power Supply
7
GND
Transmitter Signal Ground
8 TxDis
Transmitter
Disable
9
TD (+)
Transmitter Data In Non-inverted (LVPECL)
10
TD (-)
Transmitter Data In Inverted (LVPECL)
Pin Out Drawing
