K-Patents PR-23 for K-Patents Appendix - Manual (Page 10)

Document/Revision No. IM-GB-PR23-VACCINES: Rev. 1.01 Effective: November 1, 2013
10
Appendix to the Instructions Manual PR-23
2.3 Pharma Refractometer Sensor PR-23-AC-62-HSS-SC
2.3.1 Sensor Model code
Model and Description Model
PR-23 = Sensor PR-23
Sensor model
-A = 3A approved
-A
Sensor type
C = Compact type for pipe line installation
C
Refractive Index range limits
-62 = R.I. 1.320....1.530 ( 0-100 Brix )
-62
Process connection -SC
-H = Sanitary 3A-clamp, 2 ½ inch -H
Sensor wetted parts material
SS = AISI 316 L
SS
Electrical classification
-GP = General purpose
-GP
-AX = ATEX certified EX II 3 G Eex nA II T4 (up to Zone 2) -AX
-IA = ATEX and IECEx certified EX II 1 G Ex ia II C T4 Ga (up to Zone 0) (A) -IA
Sensor housing
-SC = Stainless steel
-SC
Sensor wetted parts surface treatment option
-EP = Electropolished process wetted parts (Ra 0.4µm, 15 µ inch )
-EP
(A) Available with STR- Indicating Transmitter and IS Isolator only
2.3.2 Pharma Miniflow Cell Model code
The wetted parts materials for the Pharma Miniflow Cell are AISI 316 stainless
steel standard Ra 0.4µm, 15 µ inch and EPDM (ethylene propylene diene
monomer) for the O-ring sealing.
Model and Description Model
PMFC = Pharma Mini Flowcell PMFC
Sensor connection
-H = Sanitary 3A-clamp, 2 ½ inch
-H
Material of Construction
SS = AISI 316
SS
Process connection
-H = Sanitary mini fitting
-H
Pipe section diameter
04 = 4 mm
04
05 = 5 mm 05
06 = 6 mm 06
Options
-EP = Electropolished process wetted parts (Ra 0.4µm, 15 µ inch )
-EP
