DELTA ELECTRONICS, INC.
3 Aug., 2006
Rev. 0A
www.deltaww.com
Optical Characteristics
(V
CC
=3.135V to 3.465V, Data Rate=200Mb/sec, PRBS=2 23 -1 NRZ, 62.5/125um MMF)
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Output Optical Power (Avg.)
P
O
-20 -14 dBm
Optical Extinction Ratio 9 dB
Center Wavelength
C
1310 nm
Spectral Width (RMS) 200 nm
Optical rise time/ fall time t
r
/t
f
3 ns 1
Relative Intensity Noise RIN -117 dB/Hz
Receiver
Sensitivity (Avg.)
P
IN
-31 dBm 2
Input Optical Wavelength 1100 1310 1600 nm
LOS-Deasserted (Avg.) P
A
-31 dBm
LOS-Asserted (Avg.) P
D
-48 dBm
LOS-Hysteresis P
A
-P
D
0.5 dB
Overload P
O
-14 dBm
Notes:
1. These are unfiltered 10%~90% values
2. The sensitivity is provided at a BER of 1×10 -10 or better with an input signal consisting of 200Mb/s,
2 23 -1 PRBS and ER=9dB.
