OPT-622A1F1R
DELTA ELECTRONICS, INC. 2
www.deltaww.com
Jan., 2008
Rev.：0D
Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature Ts -40 85 ºC
Lead Soldering Temperature T
SOLD
260 ºC
Lead Soldering Time t
SOLD
10 Sec.
Supply Voltage V
CC
0 6 V
Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Data Rate 622.08 Mbps
Operating Temperature T A 0 70 ºC
Supply Voltage V CC 4.75 5 5.25 V
Electrical Characteristics
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Transmitter Data Input Voltage-Low V IL -V CC -1.81 -1.48 V
Transmitter Data Input Voltage-High V IH -V CC -1.16 -0.88 V
Receiver
Data Output Voltage-Low V OL -V CC -1.95 -1.62 V
Data Output Voltage-High V OH -V CC -1.045 -0.74 V
SD Output Voltage-Low V
SDL
-V CC -1.95 -1.62 V ECL Family
SD Output Voltage-High V
SDH
-V CC -1.045 -0.74 V ECL Family
Optical Characteristics
（Data Rate = 622.08Mbps, PRBS=2 23
-1, NRZ, 62.5/125um MMF）
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Supply Current Icc 150 mA
Mean Launch Power P
O
-20 -14 dBm
Optical Extinction Ratio E.R. 9 dB
Center Wavelength λ
C
1261 1360 nm
Spectral Width (RMS) σ
14.5 nm
Optical Risetime / Falltime t
r
/t
f
3.0 ns 10%～90%
Output Eye Diagram Compliant with ITU-T recommendation G.957
Receiver
Supply Current Icc 150 mA
Sensitivity P
IN
-26 dBm
Input Optical Wavelength λ 1100 1600 nm
Signal Detect-Asserted P
A
-26 dBm
Signal Detect-DeAsserted P
D
-35 dBm
Signal Detect-Hysteresis P
A
-P
D
0.5 dB
Overload P
SAT
-8 dBm
Notes：The sensitivity should be tested at BER of 1×10
-10
or better with an input signal consisting of 622.08Mb/s,
NRZ, PRBS=2
23
-1 and E.R.= 9dB.
