SPBD-155E4J1R
DELTA ELECTRONICS, INC.
2 Revision: S1
09/20/2006
www.deltaww.com
1. Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature Ts -40 85 ºC
Operating Ambient Temperature Ta -10 80 ºC
Storage Ambient Humidity H A 5 95 %
Power Supply Voltage V CC 0 5 V
Signal Input Voltage -0.3 Vcc+0.3 V
Optical Input Power (Peak) 4 dBm
2. Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Ambient Operating Temperature T A 0 70 ºC
Ambient Humidity H A 5 85 % Non-condensing
Power Supply Voltage V CC 3.135 3.3 3.465 V
Power Supply Current I CC 250 mA
Power Supply Noise Rejection 100 mVp-p 100Hz to 1MHz
Data Rate 10 155.52 Mbps
Transmission Distance 15 km
3. Specification of Transmitter
Parameter Symbol Min. Typ. Max. Unit Note
Average Launched Power P
O
-14 -8 dBm Note (1)
Optical Extinction Ratio ER 10 dB
Center Wavelength λ
C
1260 1310 1360 nm FP Laser
Spectrum Width (RMS) σ 6 nm
Transmitter OFF Output Power P
Off
-45 dBm
Optical Rise/Fall Time t
r
/t
f
1.3 ns Note (2)
Total Jitter TJ 1 ns Note (3)
Optical Return Loss Tolerance ORLT 14 dB
Relative Intensity Noise RIN -116 dB/Hz
Dispersion Penalty TDP 1 dB
Output Eye Mask
Compliant with Bellcore TR-NWT-000253
and ITU recommendation G.957
Note (4)
Note (1). Launched power (avg.) is power coupled into a single mode fiber.
Note (2). These are unfiltered 20-80% values.
Note (3). Measure at 2
23 -1 NRZ PRBS pattern.
Note (4). Eye Mask definition
