Delta Electronics Suppression Inductors LFZ35H - Manual

* WITHSTANDING VOLTAGE BETWEEN L1 & L2 1.5KV 1 MINUTE
* GOOD DIFFERENCE IN WINDING L1 & L2 INDUCTANCE
29.0 Max.
4.0 1.0
1.0
30.0 0.3
37.0 Max.
25.0 0.3 37.0 Max.
3 2
1 4
1
2
4
3
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
Electrical Characteristics:
Mechanical Dimension:
Schematic :
LFZ35H Type
LFZ35H01 48.0 590 1.1 45
LFZ35H02 34.0 416 1.4 45
LFZ35H03 29.0 320 1.6 45
LFZ35H04 18.0 220 2.0 45
LFZ35H05 13.0 147 2.5 45
LFZ35H06 8.3 96 3.0 45
LFZ35H07 5.2 77 3.5 45
LFZ35H08 4.4 55 4.0 45
LFZ35H09 3.3 47 4.3 45
LFZ35H10 2.7 36 5.0 45
INDUCTANCE DCR RATED CURRENT TEMPERATURE
PART NO. o (mH) MIN (m ) MAX (Aac) RISE ( C) MAX
o AT 25 C, 40KHz/1V Tested:
15
Unit: mm
PRI SEC
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
Suppression Inductors
EMI Common-Mode
