VoIP Telephone Configuration Guide Page 15 of 88
The left hand navigation pane gives direct access to each of the 16 main pages, grouped by
functional headings of Network, Phone functions and Signals & Audio, plus the home page.
Most pages have an "Edit" button that allows the changing of parameters.
Some pages have entry dialog boxes that accept certain predefined values. These values
are listed in the sections below.
Some pages have links to related sub pages.
Each page displays its module name near the top for ease of navigation.
Note that these pages have been developed and tested on Microsoft Internet Explorer (v6).
Screen layout may appear differently using other browsers.
5.1 Login
To access the web pages, navigate to the unit's IP address using a web browser such as
Internet Explorer.
The factory default setting is for static IP addressing, with an address of:
192.168.1.2
Note that the unit's default subnet mask is 255.255.0.0.
The Phone will request a user name and password as shown.
Navigation
pane
Module
name
Edit button
Links to sub-
pages
Page values
