VCM Status Request:
The Controller can request the status of all the parameters in the IT-VCM with the VCM
status request:
"VCM"
Where:
"VCM" VCM
Status
Request
The VCM responds with the VCM system status response:
vcm
Ver 3.04
Serial Out Baud = 38400
Volume = -20dB
Mute On
POT Disabled
Pro Audio
Stereo Set
Treble = +10dB
Bass = +10dB
Balance = CTR
VCM
VCM
Status
Response.
Ver.
Current
Version
number
Serial Out Baud
Serial Out Baud Rate (2400, 4800, 9600, 19200, 38400, 57600).
Volume**
Volume current Level in dB (-63dB to 0dB). (See note **)
Mute
Mute
Status
(On,
Off).
Pot
Pot
Enabled
or
Disabled (set by dipswitch).
Audio
Pro or Consumer Audio type (set by dipswitch).
Stereo/Mono
Stereo or Mono audio output (set by dipswitch).
Treble
Treble Level in dB (-15dB .. 00dB .. +15dB).
Bass
Bass Level in dB (-15dB .. 00dB .. +15dB).
Balance
Balance Setting (L16..CTR..R16).
**- Format of volume level field depends on dip switch 4 setting. If dip switch 4 is "DOWN",
volume is reported in dB as shown. If "UP", it is reported as a volume step number from 0 to 63.
