Foxconn P4M800P7MA-ERS2 User Manual
Page 57
Chapter 3 BIOS Description
49
PC Health Status
v
Chassis Intrusion
This option is used to enable or disable chassis intrusion function.
v
Shutdown Temperature
This option is used to set the system temperature upper limit. When the
temperature exceeds the setting value, the motherboard will automatically cut
off power to the computer.
v
Current System/CPU Temperature
The current system/CPU temperature will be automatically detected by the
system.
v
SYSTEM/CPU FAN
The system/CPU fan speed will be automatically detected by the system.
v
Vcore/ +12V/VCC 5(V)/VCC 3.3(V)/V Battery(V)/3.3VSB (V)
The current voltages will be automatically detected by the system.
v
Smart CPU FAN Temperature
This option is used to set smart CPU fan temperature.
v
CPU FAN Tolerance Value
This option is used to set CPU fan tolerance value.
PC Health Status Menu
