3
Chapter 1 Product Introduction
Onboard LAN (-L)(-K)(optional)
· Supports 10/100/1000(-K)(optional) Mbit/sec Ethernet
· LAN interface built-in on board
Onboard Audio (-6)
· AC’97 2.3 Specification Compliant
· Supports SPDIF output
· Onboard Line-in jack, Microphone jack, Line-out jack
· Supports 6-Channel audio (setting via software)
Onboard Graphics
· Supports integrated VGA display function (S3 Graphics UniChrome TM Pro )
AGP 8X
· AGP 8X (AGP 3.0) is the VGA interface specification that enabled enhanced
graphics performance with high bandwidth speeds up to 2.12 GB/s
Green Function
· Supports ACPI (Advanced Configuration and Power Interface)
· Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(Suspend to disk - depends on OS), and S5 (soft - off)
Expansion Slots
· Three PCI slots
· One AGP slot
Advanced Features
· PCI 2.3 specification compliant
· Supports Windows 2000/XP soft-off
· Supports PC Health function (capable of monitoring system voltage, CPU
temperature, system temperature, and fan speed)
