Chapter 2 Installation Instructions
Chassis IntruderConnector: INTR(optional)
The connector connects to the chassis secu-
rity switch on the case. The system can detect
the chasis intrusion through the status of this
connector. If the connector has been closed
once, the system will send a message. To uti-
lize this function, set “Chassis Intrusion” to “En-
abled” in the “PC Health Status” section of the
CMOS Setup. Save and exit, then boot the oper-
ating system once to make sure this function
takes effect.
INTR
1 INTRUDERJ 2 GND
