Fluke Biomedical HHC3 - Manual (Page 99)

Factory Sequences
Introduction
B
B-3
Table B-1. Factory Sequences (medSim 300B) (cont.)
Dual
Keys
Sequence Segments/Selections Run Times Serial Command
ECG BPM 80
Respiration rate 20
BP1 atmosphere
BP2 atmosphere
BP3 atmosphere
BP4 atmosphere continuous
STOP
Blood pressure/artifact off
ECG BPM 80
Respiration rate 20
BP1 atmosphere
BP2 atmosphere
BP3 atmosphere
BP4 atmosphere continuous SETUP Q
G
P Monitor Setup
STOP
ECG BPM 80
Respiration rate 20
BP1 artifact
BP2 pulmonary artery
BP3 central venous pressure
BP3 left ventricle continuous STRTUP Q
H
B Monitor Start
STOP
BP1 artifact
BP2 pulmonary artery
BP3 central venous pressure
BP4 left ventricle BP/R artifact 10
Respiration wave normal
Respiration rate 20
ECG BPM 80 0:01:00 CCU
PVCs 6/min 0:09:00
PVCs 12/min 0:10:00
PVCs 24/min 0:01:00
PVCs 0/min
ECG BPM 80 0:09:00
Pair PVCs 0:01:00
ECG BPM 60 0:19:00
Paroxysmal atrial tachycardia 0:10:00
Q
H
C CCU Series
REPEAT
