Model DP569 User’s Manual
Specifications
6-3
6.2.5
Metadata Serial Port
9-pin female D-connector, electrical specifications per SMPTE 207M
Table 6-2 Metadata Serial Port Pin-Outs
Pin Connection
1 Shield
2
TX A asynchronous data out –
3
RX B asynchronous data in +
4 Ground
5 NC
6 Ground
7
TX B asynchronous data out +
8
RX A asynchronous data in –
9 Shield
6.2.6
Rear Panel Remote Control Serial Port (Remote)
9-pin female D-connector per SMPTE 207M
Table 6-3 Rear Panel Remote Control Serial Port Pin-Outs
Pin Connection
1 Shield
2
TX B asynchronous data out –
3
RX A asynchronous data in +
4 Ground
5 NC
6 Ground
7
TX A asynchronous data out +
8
RX B asynchronous data in –
9 Shield
