59
Pos Part no. Description
1 D3E-SP2 Front cover incl. screw
2 D3E-SP3 Terminal cover incl. screw
3 D3E-SP4 Internal cover incl. screws
4 P5-Sxx Spindle adapter
5 D3-SP1 Block compl. incl. cable, rubber seal, filter-plug
6 D3-SP9 Filter plug incl.O-ring, filter
7 D3E-SP8 Potentiometer compl. incl. spring, holder, cable
8 D3E-SP8-270 Potentiometer compl. incl. spring, holder, cable
9 D3E-SP20 Shaft compl. incl. gearwheel, friction clutch
10 D3E-SP20-270 Shaft compl. incl. gearwheel, friction clutch
11 D3-SP37 Display pcb
12 D3E-SP35X All PCB´s, (processor, mother, terminal)
13 D3E-SP35H All PCB´s, HART, (processor, mother, terminal)
14 D3E-SP40 Terminal PCB
15 D3E-SP/Screw Kit with screws D3E
16 D3E-SP/Seal Kit with O-rings
17 D3E-SP42 Cable for pneumatic block, incl. 2 x PCB
18 D3E-SP46G Dump valve G assy for D3E
19 D3E-SP46N Dump valve NPT assy for D3E
20 D3E-SP18 Adapter complete for dump valv assy
