34
Temp Alarm based on temperature
On/Off Temperature alarm on/off.
Low temp Temperature setting.
High temp Temperature setting.
Hysteresis Allowed hysteresis.
Alarm out Select ON/OFF offers output on terminals 13 and 14.
Valve act Behaviour of valve when alarm is generated.
FULL MENU
FACT SET
Valve act
No action Alarm generated only. Operations not affected.
Goto open C+ gives full pressure and valve moves to fully
open position. Positioner changes to position
Manual.
Goto close C- gives full pressure and valve moves to fully
closed position. Positioner changes to position
Manual.
Manual Valve stays in unchanged position. Positioner
moves to position Manual.
The menu contents are shown in the chart on the next page and the various texts are
described below:
The default values that were set on delivery can be reset using the Fact Set menu. Values
from calibration and from other settings will then be lost.
