48
10. Technical data
Rotation angle min. 30 ° max 100°
Stroke 5 - 130 mm (0.2” to 5.1”)
Input signal 4 - 20 mA
Air supply 2 - 7 bar (30 - 87 psi) Free from oil, water
and moisture. Filtered to min. 30 micron
Air delivery 400 nl/min (13.8 scfm)
Air consumption <0.3 nl/min (0.01 scfm)
Air connections 1/4” G or NPT
Cable entry 3 x M20 or 1/ 2” NPT
Electrical connections Screw terminals 2.5 mm 2 /AWG14
Linearity <1%
Repeatability <0.5%
Hysteresis <0.4%
Dead band 0.2-10% adjustable
Display Graphic, view area 15 x 41mm (0.6 x 1.6”)
UI 5 push buttons
Processor 16 bit, M 16C
CE directives 93/68EEC, 89/336/EEC, 92 /31/EEC
EMC EN 50 081-2, EN 50 082-2
Voltage drop <10.1V
Vibrations <1% up to 10 g at frequency 10 - 500 Hz
Enclosure IP66/NEMA 4X
Material Die-cast aluminium, A2/A4 fasteners
Surface treatment Powder epoxy
Temperatur range –30 to +80 °C (–22 to 176° F)
Weight D3X, 1.4 kg (3 lbs). D3E, 3 kg (6.6 lbs)
Alarm output Transistor Ri 1K Ω
Alarm Supply Voltage 8 - 28 V
