LNGT USER INSTRUCTIONS ENGLISH 00083107 02-08
Page 36 of 48
®
6.9.12 Assembly of the remaining components
ƒ Assemble the coupling between the pump unit
and the electric motor according to the
instructions provided by the relevant supplier.
ƒ If required, replace the gaskets between the
flanges of the pipe work.
ƒ Connect all auxiliary lines according to the
dimensioned sketch. Fit the protective cover at
the coupling.
ƒ Carry out the instructions for starting up the
pump.
6.9.13 Stuffing box assembly
6.9.13.1 Gland packing
Insert inner two rings of packing, then lantern ring
halves and finally 2 or 3 more rings of packing.
Loosely fit the gland [4120] and connect flush line.
6.9.13.2 Component mechanical seal [4200.1]
Refer to separate User Instructions supplied
with the mechanical seal.
Fasten seal covers [4213] complete with O-ring
[4610.9] using screws [6570.7]. Connect flush line.
Connect any auxiliary piping.
6.9.13.3 Cartridge mechanical seal [4200]
If optional cartridge seals are fitted, refer to
separate User Instructions supplied with the seal
for securing and activating the seal.
