PART NUMBERING SYSTEM
S 24 S A 1R8
12 N
R
F
A
Form
Factor
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF
Logic
Pin Type
Option
Code
S- Small
Power
24V
S- Single
A- Advanced 1R2-1.2V
1R5-1.5V
1R8-1.8V
2R5-2.5V
3R3- 3.3V
050- 5.0V
120- 12.0V
03- 3.0A
06- 6.6A
10- 10A
12- 12A
N- Negative
P- Positive
R- SMD
T- Through
hole
F- RoHS 6/6
(Lead Free)
A－6 pins, no
sense
B－8 pins, with
sense
MODEL LIST
MODEL NAME
INPUT
OUTPUT
EFF @ 100% LOAD
S24SA1R212NRFA 18V~36V 2.2A 1.2V 12A
85.5%
S24SA1R512NRFA 18V~36V 2.2A 1.5V 12A
87.0%
S24SA1R812NRFA 18V~36V 2.2A 1.8V 12A
87.5%
S24SA2R510NRFA 18V~36V 3.2A 2.5V 10A
88.5%
S24SA3R310NRFA 18V~36V 3.2A 3.3V 10A
90.0%
S24SA05006NRFA
18V~36V
3.2A 5.0V 6.6A
90.0%
S24SA12003NRFA 18V~36V 3.2A 12V 3.0A
89.5%
CONTACT:
www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email:
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for
its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license is
granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these
specifications at any time, without notice
.
