DATASHEET
DS_S24SA1R812_05092006

Delta Electronics, Inc.

Delphi Series S24SA, 2”x1” Family
DC/DC Power Modules: 18~36Vin,

1.8V, 12A out

The Delphi Series S24SA, surface mountable, 24V input, single output,
isolated DC/DC converter is the latest offering from a world leader in
power system and technology and manufacturing -- Delta Electronics, Inc.
This product family provides up to 36 watts of power or up to 12A of
output current (for output voltage 1.8V or below) in a low profile 2”x1”
industry standard form factor and pinout. The S24SA operates from a
wide input range of 18V to 36V, output ranges from 1.2V to 12V.

For 1.8V

at 12A full load, the efficiency is up to 87.5%. With creative design
technology and optimization of component placement, these converters
possess outstanding electrical and thermal performance, as well as
extremely high reliability under highly stressful operating conditions. All
models are protected from abnormal input/output voltage and current
conditions, and feature 2250V input/output isolation and basic insulation.

APPLICATIONS

Telecom/DataCom

Wireless Networks

Optical Network Equipment

Server and Data Storage

Industrial/Test Equipment

OPTIONS

Positive on/off logic

SMD or Through hole mounting

FEATURES

High efficiency: 87.5% @ 1.8V/ 12A

Size: 47.2mm x 29.5mm x 8.5mm

(1.86" x 1.16" x 0.33")

Low profile: 0.33"

Industry standard footprint and pin out

Surface mountable

Fixed frequency operation

Input UVLO, Output OCP, OVP, OTP

No minimum load required

2:1 input voltage range

Basic insulation

2250 isolation

ISO 9001, TL 9000, ISO 14001, QS9000,

OHSAS18001 certified manufacturing facility

UL/cUL 60950 (US & Canada) recognized,

and TUV (EN60950) certified
