F18 Series Service and Installation Manual
11
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
Delfield
™
®
1 2 3 4
Refrigerator Freezer Cartridge only Drawer box Divider Intermediate Intermediate
*Cartridge assy *Cartridge assy (no fronts, no mullions) Bar(s) Left Track Right Track
32" lo profile 000-aew-0030 000-aew-003a RF700100 000-333-0034 264-018-0032, 264-018-0034 3234504 3234492
27" lo profile 000-aew-0031 000-aew-003b RF700101 000-333-0035 264-018-0033 3234517 3234509
24" lo profile 000-aew-0032 000-aew-003c RF700102 000-333-0036 264-018-0036, 264-018-0037 3234504 3234492
19" lo profile 000-aew-0033 000-aew-003d RF700103 000-333-0037 **264-018-0038 3234504 3234492
32" 3 high mk7 000-aew-0034 000-aew-003e RF700104 000-333-0034 264-018-0032, 264-018-0034 3234504 3234492
27" 3 high mk7 000-aew-0035 000-aew-003f RF700105 000-333-0035 264-018-0033 3234517 3234509
24" 3 high mk7 000-aew-0036 000-aew-003g RF700106 000-333-0036 264-018-0036, 264-018-0037 3234504 3234492
19" 3 high mk7 000-aew-0037 000-aew-003h RF700107 000-333-0037 **264-018-0038 3234504 3234492
32" 2 high mk7 000-aew-0038 000-aew-003i RF700108 000-333-0034 264-018-0032, 264-018-0034 3234504 3234492
27" 2 high mk7 000-aew-0039 000-aew-003j RF700109 000-333-0035 264-018-0033 3234517 3234509
24" 2 high mk7 000-aew-0040 000-aew-003k RF700110 000-333-0036 264-018-0036, 264-018-0037 3234504 3234492
19" 2 high mk7 000-aew-0041 000-aew-003l RF700111 000-333-0037 **264-018-0038 3234504 3234492
5 6 7 8 9 10 11
Refrigerator Freezer Drawer front Drawer front Drawer front Drawer front Gasket
Mullion Mullion assy assy, top assy,middle assy, bottom
32" low profile 000-315-0033 000-315-003b 000-328-0033 na na na 1701197
27" low profile 000-315-0032 000-315-003a 000-328-0032 na na na 1701196
24" low profile 000-315-0031 000-315-0039 000-328-0031 na na na 1701195
19" low profile 000-315-0030 000-315-0038 000-328-0030 na na na 1701194
32" 3 high mk7 000-315-0033 000-315-003b na 000-328-0037 000-328-0033 000-328-003b 1701197
27" 3 high mk7 000-315-0032 000-315-003a na 000-328-0036 000-328-0032 000-328-003a 1701196
24" 3 high mk7 000-315-0031 000-315-0039 na 000-328-0035 000-328-0031 000-328-0039 1701195
19" 3 high mk7 000-315-0030 000-315-0038 na 000-328-0034 000-328-0030 000-328-0038 1701194
32" 2 high mk7 000-315-0037 000-315-003f 000-327-0033 na na na 1701193
27" 2 high mk7 000-315-0036 000-315-003e 000-327-0032 na na na 1701192
24" 2 high mk7 000-315-0035 000-315-003d 000-327-0031 na na na 1701191
19" 2 high mk7 000-315-0034 000-315-003c 000-327-0030 na na na 1701190
Cartridge Style Drawer Systems
*Complete cartridge assembly includes: cartridge, drawer boxes, drawer fronts, and mullion.
**264-018-0038: Divider bar can also be used in all drawer boxes for 1/6 size pan applications.
See page 12 for blow-out model diagram.
