38 DR ® 22-TON VERTICAL/HORIZONTAL WOOD SPLITTER
Chapter 6: Parts Lists, Schematic Diagrams And Warranty
Parts List – Base Unit
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 229741 Weldment, Base Tank
2 229751 Bolt, 5/16-18 x 3/4" long
3 229761 Fender
4 229771 Locknut,
5/16-18
5 229781 Seal, Inside
6 229791 Bearing, Tapered Roller
7 229801 Hub, Studded
8 229811 Tire, 4.8" x 8"
9 229821 Washer, Thrust
10 229831 Key, Cotter, 1/8"
11 229841 Dust Cap
12 229851 Nut, Spindle
13 229861 Nut, Lug
14 229871 Bolt, 5/16-18 x 1-3/4" long
15 229881 Washer, 5/16"
16 229891 Lock Washer, 5/16"
17 229901 Nut, 5/16-18
18 229911 Plug, Vented Fill
19 229921 O-ring, Vented Fill Plug
23 229961 Pin, Hinge
Ref# Part# Description
24 229971 Clip, Hairpin, 3/32 x 2-1/2" long
25 229981 Pin, Plunger
26 229991 Spring
27 230001 Pin, Slotted Spring, 3/16" dia.
28 230011 Knob, Bar
29 230021 Bracket, Hinge
30 229951 Nut, 1/2-13
31 229941 Lock Washer, 1/2"
32 229931 Bolt, 1/2-13 x 1-1/2" long
33 230031 Weldment, Tongue
34 230041 Weldment, Front Leg
35 230051 Coupler, Hitch, 2"
36 230061 Chain Assembly
37 230071 Bolt, 1/2-13 x 3-1/2" long
38 230081 Safety Quick-Link
39 230091 Locknut, 1/2-13
40 230101 Plug Cap
41 230111 Retaining Clip
42 230121 Jack Leg Plunger Kit
Safety & Information Labels (not shown)
230611 Label, Warning, Towing Speed
230621 Label, Notice, Hydraulic Fill
