38 TOW BEHIND DR ® FIELD and BRUSH MOWER
Parts List – Tow Bar and Remote Control Panel Assembly
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 221471 Tow Bar
02 221561 Bushing, 1.75" ID x 2.00" OD x 2.75",
Teflon
03 221491 Washer, 1.00" ID x 1.62" OD, w/Pin Hole
04 150461 Pin, Detent, 1/4" x 2", ZP
05 234981 Pin, Pivot, Tow Bar
06 221541 Pin, Spring, 1/8" x 1", ZP
07 221551 Knob, 3/8"-16, 2.5" Long x 7/8" Wide T
08 126831 Nut, Hex, 3/8"-16, ZP
09 213481 Spring, C, .660" OD x .067" Wire x 2.0"
10 234991 Washer, .53" ID x 1.06" OD x .095", ZP
11 254751 Swivel, Hitch
12 221571 Bushing, .386" ID x .623" OD x 1.915"
13 123371 Bolt, 3/8-16 x 2-3/4", HCS, GR5, ZP
14 112391 Washer, Flat, 3/8", USS, ZP
15 110751 Nut, Nylon Lock, 3/8"-16, ZP
16 211551 Pin, Snap Safety, 3/8" x 2-3/4"
17 211541 Pin, Clevis, 1/2" x 3.5" L, ZP
18 160031 Pin, Hitch Clip, 1/2" to 9/16"
19 213251 Control Panel
20 222231 Switch, Snap-In, Electric Start
Ref# Part# Description
21 157201 Key, Ignition Switch
22 191231 Switch, Push/Pull, TPDT
23 222241 Cable & Lever, Throttle, 154" (15HP
Kohler)
222481 Cable & Lever, Throttle, 170" (20HP
Kohler)
24 230911 Knob, 3/8"-24, Mount, 1.12" OD
25 114781 Screw, 10-24 x 5/8", Phil Pan, ZP
26 118731 Nut, Nylon Lock, 10-24, ZP
27 222261 Wire Harness, Control
28 230811 Strain Relief, 1/2" Cord
29 235001 Pin, Cotter, 7/64" x 1", ZP
30 164841 Bolt, 3/8-16 x 2-1/2", HCS, ZP
31 254761 Tongue, TB1 Hitch
32 265561 Bolt, 1/2-13 x 2-3/4", HCS, ZP
33 110721 Locknut, 1/2-13
34 265521 Extender, Hitch
Items Not Illustrated
191651 Strap, Hook and Loop
111581 Bolt, 5/16-18 x 1", HCS, GR5, ZP
Safety and Information Labels
222221 Label, Control Panel
127811 Label, Warning, Add Oil
